DSC1102AI2-156.2540T
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
Standard Clock Oscillators MEMS Oscillator, High Perf, Single LVPECL Output, -40C-85C, 25ppm
PDF
/
Buying Options
Total Price: USD $3.75
Unit Price: USD $3.7488
≥1 USD $3.7488
≥10 USD $3.56312
≥100 USD $3.37568
Inventory: 1048
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, No Lead
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series DSC1102
Size / Dimension 0.276Lx0.197W 7.00mmx5.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination Solder
Type XO (Standard)
Voltage - Supply 2.25V~3.6V
Frequency 156.254MHz
Frequency Stability ±25ppm
Output LVPECL
Function Standby (Power Down)
Base Resonator MEMS
Current - Supply (Disable) (Max) 95μA
Max Supply Current 58mA
Max Duty Cycle 52 %
Dimensions
Height 889μm
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status ROHS3 Compliant
