DSC1101DM1-033.3330
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS OSC XO 33.3330MHZ CMOS SMD
PDF
/
Buying Options
Total Price: USD $1.18
Unit Price: USD $1.178984
≥1 USD $1.178984
≥200 USD $0.456889
≥500 USD $0.439822
≥1000 USD $0.431944
Inventory: 1601
Minimum: 1
-
+
Technical Details
Technical
Max Supply Current 35mA
Current - Supply (Disable) (Max) 95μA
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Operating Frequency 33.333MHz
Physical Dimension 2.5mm x 2.0mm x 0.9mm
Base Resonator MEMS
Function Standby (Power Down)
Output CMOS
Frequency Stability ±50ppm
Frequency 33.333MHz
Voltage - Supply 2.25V~3.6V
Terminal Finish Matte Tin (Sn)
Type XO (Standard)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Series DSC1101
Packaging Tube
Operating Temperature -55°C~125°C
Dimensions
Height 889μm
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 26 Weeks
