DSC1101DI5-030.2400T
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS RoHS Compliant Standby (Power Down) Active crystal oscillator 55/45% -40C~85C 2ns 35mA
PDF
/
Inventory: 7711
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 6-SMD, No Lead
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series DSC1101
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type XO (Standard)
Terminal Finish Matte Tin (Sn)
Additional Feature STANDBY; ENABLE/DISABLE FUNCTION; TR
Voltage - Supply 2.25V~3.6V
Reach Compliance Code compliant
Frequency 30.24MHz
Frequency Stability ±10ppm
Output CMOS
Function Standby (Power Down)
Base Resonator MEMS
Current - Supply (Max) 35mA
Physical Dimension 2.5mm x 2.0mm x 0.9mm
Operating Frequency 30.24MHz
Rise Time-Max 2ns
Fall Time-Max 2ns
Symmetry-Max 55/45%
Current - Supply (Disable) (Max) 95μA
Dimensions
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status RoHS Compliant
