DSC1101CE5-100.0000T

Microchip Technology
RoHS
RoHS RoHS compliant
Package 6-VDFN
Category Crystals, Oscillators, Resonators / Oscillators
Description MEMS RoHS Compliant Standby (Power Down) Active Oscillator 55/45% -20C~70C 2ns ±10ppm
PDF
/
Inventory: 7364
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 6-VDFN
Surface Mount YES

Technical

Operating Temperature -20°C~70°C
Packaging Tape & Reel (TR)
Series DSC1101
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type XO (Standard)
Additional Feature STANDBY; ENABLE/DISABLE FUNCTION; TR
Voltage - Supply 2.25V~3.6V
Reach Compliance Code compliant
Frequency 100MHz
Output CMOS
Function Standby (Power Down)
Base Resonator MEMS
Current - Supply (Max) 35mA
Physical Dimension 3.2mm x 2.5mm x 0.85mm
Operating Frequency 100MHz
Rise Time-Max 2ns
Fall Time-Max 2ns
Symmetry-Max 55/45%
Current - Supply (Disable) (Max) 95μA
Absolute Pull Range (APR) ±10ppm

Dimensions

Height Seated (Max) 0.035 0.90mm

Compliance

RoHS Status RoHS Compliant
