DSC1101CE5-025.0000
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS OSC XO 25.0000MHZ CMOS SMD
PDF
/
Inventory: 8171
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, No Lead
Technical
Operating Temperature -20°C~70°C
Packaging Tube
Series DSC1101
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Type XO (Standard)
Voltage - Supply 2.25V~3.6V
Frequency 25MHz
Frequency Stability ±10ppm
Output CMOS
Function Standby (Power Down)
Base Resonator MEMS
Physical Dimension 3.2mm x 2.5mm x 0.9mm
Operating Frequency 25MHz
Max Supply Current 35mA
Current - Supply (Disable) (Max) 95μA
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.035 0.90mm
Height 889μm
