DSC1033DC1-004.7500T
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
Standard Clock Oscillators MEMS Oscillator, 3.3V, 0C-70C, 50 ppm
PDF
/
Inventory: 2701
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD, No Lead
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Series DSC1033, PureSilicon?
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination Solder
Type XO (Standard)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Voltage - Supply 3.3V
Frequency 4.75MHz
Frequency Stability ±50ppm
Output CMOS
Function Standby (Power Down)
Base Resonator MEMS
Current - Supply (Max) 3mA Typ
Operating Supply Voltage 3.3V
Current - Supply (Disable) (Max) 1μA
Max Supply Voltage 3.6V
Min Supply Voltage 3V
Load Capacitance 15pF
Max Supply Current 3mA
Max Duty Cycle 55 %
Dimensions
Height 889μm
Height Seated (Max) 0.035 0.90mm
Length 2.4892mm
Width 2.0066mm
Compliance
RoHS Status ROHS3 Compliant
