DSC1001DL2-013.5000
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS OSC XO 13.5000MHZ CMOS SMD
PDF
/
Inventory: 2438
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q100
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.035 0.90mm
Technical
Current - Supply (Disable) (Max) 15μA
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Operating Frequency 13.5MHz
Physical Dimension 2.5mm x 2.0mm x 0.85mm
Current - Supply (Max) 6.3mA
Base Resonator MEMS
Function Standby (Power Down)
Output CMOS
Frequency Stability ±25ppm
Frequency 13.5MHz
Supply Voltage 3.3V
Voltage - Supply 1.8V~3.3V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type XO (Standard)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Series DSC1001
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Surface Mount YES
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
