DSC1001CI5-060.0000
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS OSC XO 60.0000MHZ CMOS SMD
PDF
/
Buying Options
Total Price: USD $2.29
Unit Price: USD $2.291788
≥1 USD $2.291788
≥10 USD $2.162063
≥100 USD $2.039683
≥500 USD $1.924228
≥1000 USD $1.815313
Inventory: 1158
Minimum: 1
-
+
Technical Details
Technical
Frequency Stability ±10ppm
Output CMOS
Function Enable/Disable
Base Resonator MEMS
Physical Dimension 3.2mm x 2.5mm x 0.9mm
Operating Frequency 60MHz
Rise Time-Max 2ns
Fall Time-Max 2ns
Symmetry-Max 55/45%
Current - Supply (Disable) (Max) 15μA
Max Supply Current 7.2mA
Frequency 60MHz
Supply Voltage 3.3V
Voltage - Supply 1.8V~3.3V
Additional Feature ALSO OPERATES AT 2.5V AND 1.8V SUPPLY VOLTAGE
Type XO (Standard)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series DSC1001
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Height 889μm
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q100
Physical
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
