DSC1001CI2-016.9344

Microchip Technology
RoHS
RoHS RoHS compliant
Package 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description MEMS OSC XO 16.9344MHZ CMOS SMD
PDF
/
Inventory: 9260
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD, No Lead

Technical

Operating Temperature -40°C~85°C
Packaging Tube
Series DSC1001
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Type XO (Standard)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Supply 1.8V~3.3V
Frequency 16.9344MHz
Frequency Stability ±25ppm
Output CMOS
Function Standby (Power Down)
Base Resonator MEMS
Current - Supply (Max) 6.3mA
Current - Supply (Disable) (Max) 15μA
Max Supply Current 6.3mA

Dimensions

Height 889μm
Height Seated (Max) 0.035 0.90mm
Length 3.2004mm
Width 2.4892mm

Compliance

RoHS Status ROHS3 Compliant
Ratings AEC-Q100
