DSC1001CI2-004.0960
RoHS
RoHS compliant
RoHS compliantPackage 4-VDFN
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS RoHS Compliant Standby (Power Down) Active Oscillator 55/45% -40C~85C 2ns 8mA
PDF
/
Inventory: 9443
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 4-VDFN
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series DSC1001
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type XO (Standard)
Terminal Finish Matte Tin (Sn)
Voltage - Supply 1.7V~3.6V
Supply Voltage 3.3V
Reach Compliance Code compliant
Frequency 4.096MHz
Frequency Stability ±25ppm
Output CMOS
Function Standby (Power Down)
Base Resonator MEMS
Current - Supply (Max) 8mA
Physical Dimension 3.2mm x 2.5mm x 0.85mm
Operating Frequency 4.096MHz
Rise Time-Max 2ns
Fall Time-Max 2ns
Symmetry-Max 55/45%
Current - Supply (Disable) (Max) 15μA
Dimensions
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status RoHS Compliant
Ratings AEC-Q100
