DSC1001CE2-013.5600T
RoHS
RoHS compliant
RoHS compliantPackage 4-VDFN
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS RoHS Compliant Standby (Power Down) Active Oscillator 55/45% -20C~70C 2ns 8mA
PDF
/
Inventory: 6334
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q100
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.035 0.90mm
Technical
Current - Supply (Disable) (Max) 15μA
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Operating Frequency 13.56MHz
Physical Dimension 3.2mm x 2.5mm x 0.85mm
Current - Supply (Max) 8mA
Base Resonator MEMS
Function Standby (Power Down)
Output CMOS
Frequency Stability ±25ppm
Frequency 13.56MHz
Reach Compliance Code compliant
Supply Voltage 3.3V
Voltage - Supply 1.8V~3.3V
Terminal Finish Matte Tin (Sn)
Type XO (Standard)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series DSC1001
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Surface Mount YES
Package / Case 4-VDFN
Mounting Type Surface Mount
