DSC1001BE5-022.5792T
RoHS
RoHS compliant
RoHS compliantPackage 4-VDFN Exposed Pad
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS RoHS Compliant Standby (Power Down) Active crystal oscillator 55/45% -20C~70C 2ns 8mA
PDF
/
Inventory: 6538
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 4-VDFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -20°C~70°C
Packaging Tape & Reel (TR)
Series DSC1001
Size / Dimension 0.276Lx0.197W 7.00mmx5.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Type XO (Standard)
Additional Feature ALSO OPERATES AT 2.5V AND 1.8V SUPPLY VOLTAGE
Voltage - Supply 1.8V~3.3V
Supply Voltage 3.3V
Reach Compliance Code compliant
Frequency 22.5792MHz
Frequency Stability ±10ppm
Output CMOS
Function Standby (Power Down)
Base Resonator MEMS
Current - Supply (Max) 8mA
Physical Dimension 5.0mm x 3.2mm x 0.9mm
Operating Frequency 22.5792MHz
Rise Time-Max 2ns
Fall Time-Max 2ns
Symmetry-Max 55/45%
Current - Supply (Disable) (Max) 15μA
Dimensions
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status RoHS Compliant
Ratings AEC-Q100
