DSC1001BE2-027.0000C
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS OSC XO 27.0000MHZ CMOS SMD
PDF
/
Inventory: 3794
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q100
RoHS Status ROHS3 Compliant
Dimensions
Width 3.2004mm
Length 5.0038mm
Height Seated (Max) 0.035 0.90mm
Height 889μm
Technical
Max Supply Current 7.2mA
Load Capacitance 15pF
Min Supply Voltage 1.7V
Max Supply Voltage 3.6V
Current - Supply (Disable) (Max) 15μA
Current - Supply (Max) 7.2mA
Base Resonator MEMS
Function Standby (Power Down)
Output CMOS
Frequency Stability ±25ppm
Frequency 27MHz
Voltage - Supply 1.8V~3.3V
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Type XO (Standard)
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series DSC1001
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
