XUL720400.000JU6X
RoHS
/
Package CLCC
Category Crystals, Oscillators, Resonators / Oscillators
Description
Lead Free Non-RoHS Compliant Gold (Au) LVDS Oscillator 55/45% 100OHM 70C 0.4ns
PDF
/
Inventory: 7642
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case CLCC
Surface Mount YES
Mounting Feature SURFACE MOUNT
Number of Pins 6
Technical
JESD-609 Code e4
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Gold (Au)
Additional Feature ENABLE/DISABLE FUNCTION; COMPLEMENTARY OUTPUT; TAPE
HTS Code 8542.39.00.01
Subcategory Other Oscillators
Supply Voltage 2.5V
Frequency Stability 100%
Qualification Status Not Qualified
Operating Temperature (Max) 70°C
Physical Dimension 7.0mm x 5.0mm x 1.3mm
Operating Temperature (Min) -20°C
Operating Frequency 400MHz
Rise Time-Max 0.4ns
Fall Time-Max 0.4ns
Symmetry-Max 55/45%
Power Supplies 2.5V
Supply Voltage-Min (Vsup) 2.375V
Oscillator Type LVDS
Supply Current-Max 90mA
Output Load 100 OHM
Frequency Adjustment-Mechanical NO
Operating Frequency-Max 1350MHz
Dimensions
Length 7mm
Width 5mm
Thickness 1.3mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
