FXO-PC535R-100
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Gold (Au) - with Nickel (Ni) barrier LVPECL Surface Mount Oscillator 55/45% 50OHM 85C 0.4ns
PDF
/
Inventory: 1368
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.3528mm
Length 5.1562mm
Height 1.397mm
Technical
Output Load 50 OHM
Rise Time 400ps
Max Supply Current 120mA
Oscillator Type LVPECL
Min Supply Voltage 3.135V
Max Supply Voltage 3.465V
Symmetry-Max 55/45%
Fall Time-Max 0.4ns
Operating Supply Voltage 3.3V
Operating Frequency 100MHz
Physical Dimension 5.15mm x 3.35mm x 1.4mm
Frequency Stability 50 ppm
Frequency 100MHz
Supply Voltage 3.3V
Subcategory Other Oscillators
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TAPE AND REEL
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
Number of Terminations 6
JESD-609 Code e4
Physical
Number of Pins 6
Package / Case SMD/SMT
Mount Surface Mount
