FXO-LC725-200
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Gold (Au) LVDS Surface Mount crystal oscillator 55/45% 100OHM 70C 0.4ns
PDF
/
Inventory: 9806
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 5.207mm
Length 7.493mm
Height 1.397mm
Technical
Output Load 100 OHM
Max Supply Current 34mA
Oscillator Type LVDS
Supply Voltage-Min (Vsup) 2.375V
Supply Voltage-Max (Vsup) 2.625V
Symmetry-Max 55/45%
Fall Time-Max 0.4ns
Rise Time-Max 0.4ns
Operating Frequency 200MHz
Physical Dimension 7.5mm x 5.2mm x 1.4mm
Frequency Stability 50 ppm
Frequency 200MHz
Supply Voltage 2.5V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TAPE AND REEL
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Terminal Finish Gold (Au)
ECCN Code EAR99
JESD-609 Code e4
Packaging Cut Tape (CT)
Physical
Package / Case SMD/SMT
Mount Surface Mount
