FXO-LC535R-250
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Gold (Au) - with Nickel (Ni) barrier LVDS Surface Mount crystal oscillator 55/45% 100OHM 85C 0.4ns
PDF
/
Inventory: 4154
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case SMD/SMT
Number of Pins 6
Technical
Packaging Bulk
JESD-609 Code e4
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION ; TR 7/10 INCH
Subcategory Other Oscillators
Supply Voltage 3.3V
Frequency 250MHz
Frequency Stability 50 ppm
Physical Dimension 5.15mm x 3.35mm x 1.4mm
Operating Frequency 250MHz
Rise Time-Max 0.4ns
Fall Time-Max 0.4ns
Symmetry-Max 55/45%
Max Supply Voltage 5V
Min Supply Voltage 3.3V
Oscillator Type LVDS
Max Supply Current 100mA
Output Load 100 OHM
Dimensions
Height 1.397mm
Length 5.1562mm
Width 3.3528mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
