FXO-LC535-25
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Gold (Au) - with Nickel (Ni) barrier LVDS Surface Mount Oscillator 55/45% 100OHM 70C 0.4ns
PDF
/
Inventory: 3703
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.3528mm
Length 5.1562mm
Height 1.397mm
Technical
Output Load 100 OHM
Max Supply Current 100mA
Oscillator Type LVDS
Supply Voltage-Min (Vsup) 3.135V
Supply Voltage-Max (Vsup) 3.465V
Symmetry-Max 55/45%
Fall Time-Max 0.4ns
Rise Time-Max 0.4ns
Operating Frequency 250MHz
Physical Dimension 5.15mm x 3.35mm x 1.4mm
Frequency Stability 50 ppm
Frequency 25MHz
Supply Voltage 3.3V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION ; TR 7/10 INCH
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
JESD-609 Code e4
Physical
Package / Case SMD/SMT
Mount Surface Mount
