FXO-HC736R-66.66
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Gold (Au) - with Nickel (Ni) barrier HCMOS Surface Mount crystal oscillator 55/45% 15pF 85C 3ns
PDF
/
Inventory: 9856
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 5.207mm
Length 7.493mm
Height 1.397mm
Technical
Output Load 15 pF
Max Supply Current 47mA
Oscillator Type HCMOS
Supply Voltage-Min (Vsup) 3.135V
Supply Voltage-Max (Vsup) 3.465V
Symmetry-Max 55/45%
Fall Time-Max 3ns
Rise Time-Max 3ns
Operating Frequency 66.66MHz
Physical Dimension 7.5mm x 5.2mm x 1.4mm
Frequency Stability 25 ppm
Frequency 66.66MHz
Supply Voltage 3.3V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TAPE AND REEL
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e4
Packaging Cut Tape (CT)
Physical
Package / Case SMD/SMT
Mount Surface Mount
