FXO-HC730R-15
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Gold (Au) - with Nickel (Ni) barrier HCMOS Surface Mount crystal oscillator 55/45% 15pF 85C 3ns
PDF
/
Inventory: 1478
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 5.207mm
Length 7.493mm
Height 1.397mm
Technical
Output Load 15 pF
Max Supply Current 32mA
Load Capacitance 30pF
Oscillator Type HCMOS
Symmetry-Max 55/45%
Fall Time-Max 3ns
Rise Time-Max 3ns
Operating Supply Voltage 3.3V
Operating Frequency 15.96MHz
Physical Dimension 7.5mm x 5.2mm x 1.4mm
Frequency Stability 100 ppm
Frequency 15MHz
Supply Voltage 3.3V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TAPE AND REEL
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e4
Packaging Bulk
Physical
Number of Pins 6
Package / Case SMD/SMT
Mount Surface Mount
