FXO-HC730-20
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description
OSC XO 20.000MHZ HCMOS SMD
PDF
/
Inventory: 8832
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case SMD/SMT
Number of Pins 6
Technical
Packaging Tape & Reel
JESD-609 Code e4
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 70°C
Min Operating Temperature -20°C
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TR, 7 INCH
Subcategory Other Oscillators
Supply Voltage 3.3V
Frequency 20MHz
Frequency Stability 100 ppm
Physical Dimension 7.5mm x 5.2mm x 1.4mm
Operating Frequency 20MHz
Rise Time-Max 3ns
Fall Time-Max 3ns
Symmetry-Max 55/45%
Max Supply Voltage 5V
Min Supply Voltage 3.3V
Oscillator Type HCMOS
Load Capacitance 15pF
Max Supply Current 32mA
Dimensions
Height 1.397mm
Length 7.493mm
Width 5.207mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
