FXO-HC726-25
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Gold (Au) - with Nickel (Ni) barrier HCMOS Surface Mount crystal oscillator 55/45% 15pF 70C 3.5ns
PDF
/
Inventory: 8320
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 5.207mm
Length 7.493mm
Height 1.397mm
Technical
Output Load 15 pF
Max Supply Current 25mA
Oscillator Type HCMOS
Supply Voltage-Min (Vsup) 2.375V
Supply Voltage-Max (Vsup) 2.625V
Symmetry-Max 55/45%
Fall Time-Max 3.5ns
Rise Time-Max 3.5ns
Operating Frequency 25MHz
Physical Dimension 7.5mm x 5.2mm x 1.4mm
Frequency Stability 25 ppm
Frequency 25MHz
Supply Voltage 2.5V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TR, 7/10 INCH
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
JESD-609 Code e4
Physical
Package / Case SMD/SMT
Mount Surface Mount
