FXO-HC526R-20
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Gold (Au) - with Nickel (Ni) barrier HCMOS Surface Mount Oscillator 15pF 85C 3.5ns 22mA
PDF
/
Inventory: 9714
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case SMD/SMT
Number of Pins 4
Technical
JESD-609 Code e4
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TR, 7/10 INCH
Supply Voltage 2.5V
Frequency 20MHz
Frequency Stability 25 ppm
Operating Frequency 20MHz
Rise Time-Max 3.5ns
Fall Time-Max 3.5ns
Max Supply Voltage 2.625V
Min Supply Voltage 2.375V
Oscillator Type HCMOS
Load Capacitance 15pF
Max Supply Current 22mA
Dimensions
Height 1.397mm
Length 5.1562mm
Width 3.3528mm
Compliance
RoHS Status RoHS Compliant
