768-15.36-5
RoHS
/
Package /
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Gold (Au) - with Nickel (Ni) barrier HCMOS SURFACE MOUNT crystal oscillator 55/45% 15pF 85C 3ns
PDF
/
Inventory: 5186
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Mounting Feature SURFACE MOUNT
Technical
JESD-609 Code e4
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TR, 7/10 INCH
Supply Voltage 3.3V
Frequency Stability 50%
Operating Temperature (Max) 85°C
Physical Dimension 7.5mm x 5.2mm x 1.4mm
Operating Temperature (Min) -40°C
Operating Frequency 15.36MHz
Rise Time-Max 3ns
Fall Time-Max 3ns
Symmetry-Max 55/45%
Supply Voltage-Max (Vsup) 3.465V
Supply Voltage-Min (Vsup) 3.135V
Oscillator Type HCMOS
Output Load 15 pF
Frequency Adjustment-Mechanical NO
Compliance
RoHS Status RoHS Compliant
