X1G004171002412

Epson
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description CMOS 2014 RoHS Compliant CMOS Oscillator 15pF 85C 3.5ns 1.8mA
PDF
/
Inventory: 5575
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 2mm
Length 2.5mm
Height 800μm

Technical

Supply Current-Max 1.8mA
Load Capacitance 15pF
Oscillator Type CMOS
Min Supply Voltage 1.6V
Max Supply Voltage 3.6V
Fall Time-Max 3.5ns
Rise Time-Max 3.5ns
Operating Frequency 14.31818MHz
Physical Dimension 2.5mm x 2mm x 0.8mm
Frequency Stability 50 ppm
Frequency 14.31818MHz
Technology CMOS
Additional Feature STANDBY; ENABLE/DISABLE FUNCTION
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 4
Published 2014

Physical

Number of Pins 4
Package / Case SMD/SMT
Mount Surface Mount
