ECS-TXO-5032-100-TR
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
OSC TCXO 10.000MHZ HCMOS SMD
PDF
/
Buying Options
Total Price: USD $2.3
Unit Price: USD $2.2968
≥1 USD $2.2968
≥10 USD $2.2396
≥100 USD $2.13312
≥500 USD $1.86648
≥1000 USD $1.813152
Inventory: 1160
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.059 1.50mm
Height 1.4986mm
Technical
Max Supply Current 6mA
Symmetry-Max 40/60%
Fall Time-Max 10ns
Rise Time-Max 10ns
Operating Frequency 10MHz
Physical Dimension 5.0mm x 3.2mm x 1.5mm
Base Resonator Crystal
Output HCMOS
Frequency Stability ±2.5ppm
Frequency 10MHz
Supply Voltage 3.3V
Voltage - Supply 3.3V
Additional Feature TR
Type TCXO
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series ECS-TXO-5032
Published 2015
Packaging Cut Tape (CT)
Operating Temperature -30°C~85°C
Physical
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
