EC5620TTS-12.288MTR
RoHS
/
Package /
Category Crystals, Oscillators, Resonators / Oscillators
Description
Lead Free Non-RoHS Compliant Ceramic Nickel/Gold (Ni/Au) crystal oscillator 15pF 70C 10ns 800mum
PDF
/
Inventory: 9404
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Mounting Feature SURFACE MOUNT
Number of Pins 4
Material Ceramic
Technical
JESD-609 Code e4
Terminal Finish Nickel/Gold (Ni/Au)
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TR, 7 INCH
Supply Voltage 3.3V
Frequency 12.288MHz
Frequency Stability 20 ppm
Operating Temperature (Max) 70°C
Physical Dimension 2.5mm x 2.0mm x 1.0mm
Operating Temperature (Min) -10°C
Operating Frequency 12.288MHz
Rise Time-Max 10ns
Fall Time-Max 10ns
Supply Voltage-Max (Vsup) 3.63V
Supply Voltage-Min (Vsup) 2.97V
Oscillator Type CMOS
Frequency Tolerance 0.002%
Output Load 15 pF
Dimensions
Height 800μm
Length 2.5mm
Width 2mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
