EC5620TS-14.7456MTR
RoHS
/
Package /
Category Crystals, Oscillators, Resonators / Oscillators
Description
Lead Free Non-RoHS Compliant Ceramic Nickel/Gold (Ni/Au) crystal oscillator 15pF 70C 10ns 800mum
PDF
/
Inventory: 5082
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Dimensions
Width 2mm
Length 2.5mm
Height 800μm
Technical
Output Load 15 pF
Frequency Tolerance 0.002%
Oscillator Type CMOS
Supply Voltage-Min (Vsup) 2.97V
Supply Voltage-Max (Vsup) 3.63V
Fall Time-Max 10ns
Rise Time-Max 10ns
Operating Frequency 14.7456MHz
Operating Temperature (Min) -10°C
Physical Dimension 2.5mm x 2.0mm x 1.0mm
Operating Temperature (Max) 70°C
Frequency Stability 20 ppm
Frequency 14.7456MHz
Supply Voltage 3.3V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TR, 7 INCH
Terminal Finish Nickel/Gold (Ni/Au)
JESD-609 Code e4
Physical
Material Ceramic
Number of Pins 4
Mounting Feature SURFACE MOUNT
Surface Mount YES
