EC2700TS-16.384MTR
RoHS
/
Package /
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Ceramic Nickel/Gold (Ni/Au) LVCMOS Oscillator 15pF 70C 6ns 7.0mm x 5.0mm x 1.6mm
PDF
/
Inventory: 8211
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Mounting Feature SURFACE MOUNT
Number of Pins 4
Material Ceramic
Technical
JESD-609 Code e4
Pbfree Code yes
Terminal Finish Nickel/Gold (Ni/Au)
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TAPE AND REEL
Supply Voltage 2.5V
Reach Compliance Code compliant
Frequency 16.384MHz
Frequency Stability 100 ppm
Operating Temperature (Max) 70°C
Physical Dimension 7.0mm x 5.0mm x 1.6mm
Operating Temperature (Min) -10°C
Operating Frequency 16.384MHz
Rise Time-Max 6ns
Fall Time-Max 6ns
Supply Voltage-Max (Vsup) 2.625V
Supply Voltage-Min (Vsup) 2.375V
Oscillator Type LVCMOS
Frequency Tolerance 0.01%
Output Load 15 pF
Compliance
RoHS Status RoHS Compliant
