EC2645TTS-18.432M
RoHS
/
Package /
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Ceramic Nickel/Gold (Ni/Au) LVCMOS Oscillator 30pF 70C 5ns 7.0mm x 5.0mm x 1.6mm
PDF
/
Inventory: 2294
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Output Load 30 pF
Frequency Tolerance 0.005%
Oscillator Type LVCMOS
Supply Voltage-Min (Vsup) 2.97V
Supply Voltage-Max (Vsup) 3.63V
Fall Time-Max 5ns
Rise Time-Max 5ns
Operating Frequency 18.432MHz
Operating Temperature (Min) -10°C
Physical Dimension 7.0mm x 5.0mm x 1.6mm
Operating Temperature (Max) 70°C
Pin Count 4
Frequency Stability 50 ppm
Frequency 18.432MHz
Reach Compliance Code compliant
Supply Voltage 3.3V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION
Terminal Finish Nickel/Gold (Ni/Au)
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e4
Physical
Material Ceramic
Number of Pins 4
Mounting Feature SURFACE MOUNT
Surface Mount YES
