EC2600TS-24.576M

Ecliptek
RoHS
/
Package /
Category Crystals, Oscillators, Resonators / Oscillators
Description RoHS Compliant Ceramic Nickel/Gold (Ni/Au) SMD/SMT Oscillator 30pF 70C 5ns 7.0mm x 5.0mm x 1.6mm
PDF
/
Inventory: 7630
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Frequency Tolerance 0.01%
Load Capacitance 30pF
Oscillator Type LVCMOS
Min Supply Voltage 2.97V
Max Supply Voltage 3.63V
Fall Time-Max 5ns
Rise Time-Max 5ns
Operating Supply Voltage 3.3V
Operating Frequency 24.576MHz
Physical Dimension 7.0mm x 5.0mm x 1.6mm
Pin Count 4
Frequency Stability 100 ppm
Frequency 24.576MHz
Supply Voltage 3.3V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION
Min Operating Temperature -10°C
Max Operating Temperature 70°C
Terminal Finish Nickel/Gold (Ni/Au)
ECCN Code EAR99
Termination SMD/SMT
Pbfree Code yes
JESD-609 Code e4
Packaging Bulk

Physical

Material Ceramic
Number of Pins 4
Mounting Feature SURFACE MOUNT
Surface Mount YES
