EC2600ETTTS-64.000M
RoHS
/
Package /
Category Crystals, Oscillators, Resonators / Oscillators
Description
RoHS Compliant Ceramic Nickel/Gold (Ni/Au) LVCMOS Oscillator 15pF 85C 3ns 7.0mm x 5.0mm x 1.6mm
PDF
/
Inventory: 1500
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Mounting Feature SURFACE MOUNT
Number of Pins 4
Material Ceramic
Technical
JESD-609 Code e4
Pbfree Code yes
ECCN Code EAR99
Terminal Finish Nickel/Gold (Ni/Au)
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION
Supply Voltage 3.3V
Reach Compliance Code compliant
Frequency 64MHz
Frequency Stability 100 ppm
Pin Count 4
Operating Temperature (Max) 85°C
Physical Dimension 7.0mm x 5.0mm x 1.6mm
Operating Frequency 64MHz
Rise Time-Max 3ns
Fall Time-Max 3ns
Supply Voltage-Max (Vsup) 3.63V
Supply Voltage-Min (Vsup) 2.97V
Oscillator Type LVCMOS
Frequency Tolerance 0.01%
Output Load 15 pF
Compliance
RoHS Status RoHS Compliant
