EB16E2K2H-14.7456MTR
RoHS
/
Package /
Category Crystals, Oscillators, Resonators / Oscillators
Description
Lead Free Non-RoHS Compliant Ceramic GOLD (39) OVER NICKEL (350) Oscillator 15pF 85C 5ns 900mum
PDF
/
Inventory: 8032
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Dimensions
Width 2.5mm
Length 3.2mm
Height 900μm
Technical
Output Load 15 pF
Frequency Tolerance 0.002%
Oscillator Type CMOS
Supply Voltage-Min (Vsup) 1.71V
Supply Voltage-Max (Vsup) 1.89V
Fall Time-Max 5ns
Rise Time-Max 5ns
Operating Frequency 14.7456MHz
Physical Dimension 3.2mm x 2.5mm x 0.9mm
Operating Temperature (Max) 85°C
Frequency Stability 20 ppm
Frequency 14.7456MHz
Supply Voltage 1.8V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TR, 7 INCH
Terminal Finish GOLD (39) OVER NICKEL (350)
JESD-609 Code e4
Physical
Material Ceramic
Number of Pins 4
Mounting Feature SURFACE MOUNT
Surface Mount YES
