EB15E2G2H-33.333M
RoHS
/
Package /
Category Crystals, Oscillators, Resonators / Oscillators
Description
Lead Free Non-RoHS Compliant Ceramic Nickel/Gold (Ni/Au) Oscillator 15pF 85C 900mum 0.01%
PDF
/
Inventory: 8484
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Dimensions
Width 2.5mm
Length 3.2mm
Height 900μm
Technical
Output Load 15 pF
Frequency Tolerance 0.01%
Oscillator Type LVHCMOS
Supply Voltage-Min (Vsup) 2.375V
Supply Voltage-Max (Vsup) 2.625V
Operating Frequency 33.333MHz
Physical Dimension 3.2mm x 2.5mm x 0.9mm
Operating Temperature (Max) 85°C
Pin Count 4
Frequency Stability 100 ppm
Frequency 33.333MHz
Supply Voltage 2.5V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; BULK
Terminal Finish Nickel/Gold (Ni/Au)
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e4
Physical
Material Ceramic
Number of Pins 4
Mounting Feature SURFACE MOUNT
Surface Mount YES
