EB15E2E2H-33.333MTR

Ecliptek
RoHS
/
Package CSMD
Category Crystals, Oscillators, Resonators / Oscillators
Description Lead Free RoHS Compliant Ceramic Nickel/Gold (Ni/Au) crystal oscillator 15pF 70C 900mum 0.0025%
PDF
/
Inventory: 6240
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 2.5mm
Length 3.2mm
Height 900μm

Technical

Output Load 15 pF
Frequency Tolerance 0.0025%
Oscillator Type LVHCMOS
Supply Voltage-Min (Vsup) 2.375V
Supply Voltage-Max (Vsup) 2.625V
Operating Frequency 33.333MHz
Operating Temperature (Min) -20°C
Physical Dimension 3.2mm x 2.5mm x 0.9mm
Operating Temperature (Max) 70°C
Frequency Stability 25 ppm
Frequency 33.333MHz
Supply Voltage 2.5V
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TAPE AND REEL
Terminal Finish Nickel/Gold (Ni/Au)
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e4

Physical

Material Ceramic
Number of Pins 4
Mounting Feature SURFACE MOUNT
Surface Mount YES
Package / Case CSMD
