EB15E2C2H-3.6864MTR

Ecliptek
RoHS
/
Package /
Category Crystals, Oscillators, Resonators / Oscillators
Description Lead Free Non-RoHS Compliant Ceramic Nickel/Gold (Ni/Au) crystal oscillator 15pF 70C 5ns 900mum
PDF
/
Inventory: 3650
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Surface Mount YES
Mounting Feature SURFACE MOUNT
Number of Pins 4
Material Ceramic

Technical

JESD-609 Code e4
Pbfree Code yes
Terminal Finish Nickel/Gold (Ni/Au)
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION; TAPE AND REEL
Supply Voltage 2.5V
Frequency 3.6864MHz
Frequency Stability 100 ppm
Operating Temperature (Max) 70°C
Physical Dimension 3.2mm x 2.5mm x 0.9mm
Operating Temperature (Min) -20°C
Operating Frequency 3.6864MHz
Rise Time-Max 5ns
Fall Time-Max 5ns
Supply Voltage-Max (Vsup) 2.625V
Supply Voltage-Min (Vsup) 2.375V
Oscillator Type LVHCMOS
Frequency Tolerance 0.01%
Output Load 15 pF

Dimensions

Height 900μm
Length 3.2mm
Width 2.5mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Lead Free
