CHT70C1607PNT
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
Crystal ROHS3Compliant Enable/Disable Active Oscillator 55/45% -55C~105C 5ns 30mA
PDF
/
Inventory: 8259
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.055 1.40mm
Technical
Current - Supply (Disable) (Max) 10μA
Symmetry-Max 55/45%
Fall Time-Max 5ns
Rise Time-Max 5ns
Operating Frequency 16MHz
Physical Dimension 7.0mm x 5.0mm x 1.4mm
Current - Supply (Max) 30mA
Base Resonator Crystal
Function Enable/Disable
Output HCMOS, TTL
Frequency Stability ±150ppm
Frequency 16MHz
Supply Voltage 2.5V
Voltage - Supply 2.5V
Type XO (Standard)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.276Lx0.197W 7.00mmx5.00mm
Series CHT70
Packaging Tape & Reel (TR)
Operating Temperature -55°C~105°C
Physical
Surface Mount YES
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
