CB3-3C-20M4800
RoHS
/
Package SMD/SMT
Category Crystals, Oscillators, Resonators / Oscillators
Description
Lead Free Gold RoHS Compliant HCMOS/TTL crystal oscillator 55/45% 50pF 70C 8ns
PDF
/
Inventory: 5423
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Surface Mount
Package / Case SMD/SMT
Technical
JESD-609 Code e4
Number of Terminations 4
Max Operating Temperature 70°C
Min Operating Temperature -20°C
Additional Feature ENABLE/DISABLE FUNCTION; TAPE AND REEL
Subcategory Other Oscillators
Supply Voltage 5V
Current Rating 30mA
Frequency 20.48MHz
Frequency Stability 50 ppm
Qualification Status Not Qualified
Physical Dimension 7.0mm x 5.0mm x 1.7mm
Operating Frequency 20.48MHz
Operating Supply Voltage 5V
Rise Time-Max 8ns
Fall Time-Max 8ns
Symmetry-Max 55/45%
Power Supplies 5V
Oscillator Type HCMOS/TTL
Load Capacitance 50pF
Max Supply Current 50mA
Frequency Tolerance 0.005%
Output Low Current-Max 16mA
Dimensions
Height 1.7018mm
Length 7.0104mm
Width 5.0038mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
