CTED-A5B3-155.52TS
RoHS
/
Package 6-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
XTAL OSC TCXO 155.5200MHZ LVPECL
PDF
/
Buying Options
Total Price: USD $91.44
Unit Price: USD $91.436921
≥1 USD $91.436921
≥200 USD $36.484178
≥500 USD $35.265807
≥1000 USD $34.663186
Inventory: 1542
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, No Lead
Technical
Operating Temperature -20°C~70°C
Packaging Tube
Series CTED
Size / Dimension 0.551Lx0.354W 14.00mmx9.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type TCXO
Max Operating Temperature 70°C
Min Operating Temperature -20°C
Voltage - Supply 3.3V
Frequency 155.52MHz
Frequency Stability ±2.5ppm
Output LVPECL
Function Enable/Disable
Base Resonator Crystal
Current - Supply (Max) 100mA
Max Supply Current 100mA
Dimensions
Height 3.5052mm
Height Seated (Max) 0.138 3.50mm
Length 13.9954mm
Width 8.9916mm
Compliance
RoHS Status RoHS Compliant
