CPPT1-A3B6-22.1184TS
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP Module, 4 Leads
Category Crystals, Oscillators, Resonators / Oscillators
Description
Crystal RoHS Compliant Enable/Disable Active crystal oscillator 125C 45mA 0.235 5.98mm 22.1184MHz
PDF
/
Inventory: 2130
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount PC Pin
Mounting Type Through Hole
Package / Case 14-DIP Module, 4 Leads
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Series FIPO? CPP
Size / Dimension 0.819Lx0.520W 20.80mmx13.20mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Supply Current 45mA
Current - Supply (Disable) (Max) 50μA
Current - Supply (Max) 45mA
Base Resonator Crystal
Function Enable/Disable
Output TTL
Frequency Stability ±100ppm
Frequency 22.1184MHz
Voltage - Supply 5V
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type XO (Standard)
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.235 5.98mm
