S21MT2
RoHS
/
Package 4-DIP (0.300, 7.62mm)
Category Isolators / Optoisolators - Triac, SCR Output
Description
OPTOISOLATOR 5KV TRIAC 4DIP
PDF
/
Buying Options
Total Price: USD $26.55
Unit Price: USD $26.5468
≥1 USD $26.5468
≥10 USD $21.7816
≥100 USD $21.1014
≥500 USD $20.42025
≥1000 USD $19.74005
Inventory: 1410
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-DIP (0.300, 7.62mm)
Technical
Operating Temperature -30°C~100°C
Packaging Tube
Published 1997
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature UL RECOGNIZED
Reach Compliance Code unknown
Approval Agency UR
Voltage - Isolation 5000Vrms
Output Voltage 420V
Output Type Triac
Number of Elements 1
Configuration SINGLE
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.2V
Output Current per Channel 100mA
Forward Current-Max 0.05A
Hold Current 100μA
Current - DC Forward (If) (Max) 50mA
Voltage - Off State 600V
Turn On Time 50μs (Max)
Current - Hold (Ih) 3.5mA
Zero Crossing Circuit Yes
Current - LED Trigger (Ift) (Max) 10mA
Static dV/dt (Min) 100V/μs
Input Trigger Current-Nom 10mA
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
