PC4SD11NTZBF
RoHS
/
Package 6-DIP (0.300, 7.62mm), 5 Leads
Category Isolators / Optoisolators - Triac, SCR Output
Description
OPTOISOLATOR 5KV TRIAC 6DIP
PDF
/
Inventory: 8647
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP (0.300, 7.62mm), 5 Leads
Number of Pins 5
Technical
Operating Temperature -30°C~100°C
Packaging Tube
Published 2004
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Copper (Sn/Cu)
Additional Feature UL RECOGNIZED
Approval Agency CSA, UR
Voltage - Isolation 5000Vrms
Output Voltage 560V
Output Type Triac
Max Output Current 100mA
Number of Elements 1
Configuration SINGLE
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.2V
Turn On Delay Time 100 μs
Forward Current 50mA
Max Input Voltage 1.4V
Nominal Input Voltage 1.2V
RMS Current (Irms) 100mA
Hold Current 3.5mA
Voltage - Off State 800V
Turn On Time 100μs (Max)
Current - Hold (Ih) 3.5mA
Zero Crossing Circuit No
Current - LED Trigger (Ift) (Max) 7mA
Static dV/dt (Min) 50V/μs
Input Trigger Current-Nom 7mA
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
