PC3ST21NSZBF
RoHS
/
Package 4-DIP (0.300, 7.62mm)
Category Isolators / Optoisolators - Triac, SCR Output
Description
OPTOISOLATOR 5KV TRIAC 4DIP
PDF
/
Inventory: 6445
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Input Trigger Current-Nom 7mA
Static dV/dt (Min) 1kV/μs
Current - LED Trigger (Ift) (Max) 7mA
Zero Crossing Circuit Yes
Current - Hold (Ih) 3.5mA
Current - On State (It (RMS)) (Max) 100mA
Turn On Time 50μs (Max)
Voltage - Off State 600V
Current - DC Forward (If) (Max) 50mA
Hold Current 100μA
Forward Current-Max 0.05A
Nominal Input Voltage 1.2V
Output Current per Channel 100mA
Max Input Voltage 1.4V
Turn On Delay Time 50 μs
Number of Channels 1
Configuration SINGLE
Number of Elements 1
Output Type Triac
Output Voltage 420V
Voltage - Isolation 5000Vrms
Approval Agency CSA, UR
Additional Feature UL RECOGNIZED
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2004
Packaging Tube
Operating Temperature -30°C~100°C
Physical
Number of Pins 4
Package / Case 4-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
