PC1S3063NTZF
RoHS
/
Package 6-DIP (0.300, 7.62mm), 5 Leads
Category Isolators / Optoisolators - Triac, SCR Output
Description
Optocoupler Triac AC-OUT 1-CH 600VDRM 5-Pin PDIP Sleeve
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.3952
≥1 USD $0.3952
≥10 USD $0.32395
≥100 USD $0.31445
≥500 USD $0.304
≥1000 USD $0.29355
Inventory: 4601
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Static dV/dt (Min) 1kV/μs
Current - LED Trigger (Ift) (Max) 5mA
Zero Crossing Circuit Yes
Current - Hold (Ih) 3.5mA
Current - On State (It (RMS)) (Max) 100mA
Turn On Time 50μs (Max)
Voltage - Off State 600V
Current - DC Forward (If) (Max) 50mA
Hold Current 3.5mA
Reverse Breakdown Voltage 6V
RMS Current (Irms) 100mA
Nominal Input Voltage 1.2V
Forward Voltage 1.2V
Output Current per Channel 100mA
Max Input Voltage 1.4V
Forward Current 50mA
Turn On Delay Time 50 μs
Voltage - Forward (Vf) (Typ) 1.2V
Output Current 100mA
Number of Channels 1
Number of Elements 1
Max Output Current 100mA
Output Type Triac
Voltage - Isolation 5000Vrms
Approval Agency UL
Min Operating Temperature -30°C
Max Operating Temperature 100°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 1998
Packaging Tube
Operating Temperature -30°C~100°C
Physical
Supplier Device Package 6-DIP
Number of Pins 5
Package / Case 6-DIP (0.300, 7.62mm), 5 Leads
Mounting Type Through Hole
Mount Through Hole
