MOC3083M
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP (0.300, 7.62mm)
Category Isolators / Optoisolators - Triac, SCR Output
Description
6-DIP (0.300 7.62mm) 1 Triac Active Optoisolator Triac Output 600V/mus 4170Vrms 60mA -40C~85C
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9416
≥1 USD $0.9416
≥10 USD $0.597872
≥100 USD $0.442464
≥500 USD $0.406595
≥1000 USD $0.334849
≥3000 USD $0.318102
Inventory: 8655
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.35mm
Length 6.35mm
Height 6.35mm
Technical
Static dV/dt (Min) 600V/μs
Current - LED Trigger (Ift) (Max) 5mA
Zero Crossing Circuit Yes
Current - Hold (Ih) 500μA Typ
Input Current 30mA
Voltage - Off State 800V
Current - DC Forward (If) (Max) 60mA
Hold Current 500μA
Max Input Current 60mA
Reverse Breakdown Voltage 6V
Nominal Input Voltage 1.3V
Forward Voltage 1.3V
Max Input Voltage 1.5V
Forward Current 60mA
Voltage - Forward (Vf) (Typ) 1.3V
Power Dissipation 250mW
Number of Circuits 1
Number of Channels 1
Number of Elements 1
Output Type Triac
Output Voltage 800V
Voltage - Isolation 4170Vrms
Approval Agency UL
Max Power Dissipation 250mW
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2008
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 855mg
Supplier Device Package 6-DIP
Number of Pins 6
Package / Case 6-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
