EL3081
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP (0.300, 7.62mm)
Category Isolators / Optoisolators - Triac, SCR Output
Description
OPTOISOLATOR 5KV TRIAC 6DIP
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.1482
≥1 USD $0.1482
≥10 USD $0.1216
≥100 USD $0.1178
≥500 USD $0.114
≥1000 USD $0.1102
≥4875 USD $0.0988
Inventory: 161529
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Input Trigger Current-Nom 15mA
Static dV/dt (Min) 600V/μs
Current - LED Trigger (Ift) (Max) 15mA
Zero Crossing Circuit Yes
Current - Hold (Ih) 280μA Typ
Voltage - Off State 800V
Current - DC Forward (If) (Max) 60mA
Hold Current 280μA
RMS Current (Irms) 100mA
Max Input Voltage 1.5V
Voltage - Forward (Vf) (Typ) 1.5V Max
Number of Channels 1
Configuration SINGLE
Number of Elements 1
Output Type Triac
Voltage - Isolation 5000Vrms
Approval Agency CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL
Additional Feature UL RECOGNIZED
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2013
Packaging Tube
Operating Temperature -55°C~100°C
Physical
Number of Pins 6
Package / Case 6-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 20 Weeks
