EL3053S1(TA)-V
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Gull Wing
Category Isolators / Optoisolators - Triac, SCR Output
Description
OPTOISOLATOR 5KV TRIAC 6SMD
PDF
/
Buying Options
Total Price: USD $0.12
Unit Price: USD $0.12445
≥1 USD $0.12445
≥10 USD $0.1026
≥100 USD $0.09975
≥500 USD $0.09595
≥1000 USD $0.0931
Inventory: 30001
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, Gull Wing
Technical
Operating Temperature -55°C~100°C
Packaging Tape & Reel (TR)
Published 2013
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Additional Feature UL RECOGNIZED, VDE APPROVED
Subcategory Optocoupler - Trigger Device Outputs
Approval Agency CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL, VDE
Voltage - Isolation 5000Vrms
Output Type Triac
Number of Elements 1
Configuration SINGLE
Number of Channels 1
Max Input Voltage 1.5V
Nominal Input Voltage 1.18V
Forward Current-Max 0.06A
Hold Current 250μA
Current - DC Forward (If) (Max) 60mA
Voltage - Off State 600V
Current - On State (It (RMS)) (Max) 100mA
Repetitive Peak Off-state Voltage 600V
Current - Hold (Ih) 250μA Typ
Zero Crossing Circuit No
Current - LED Trigger (Ift) (Max) 5mA
Static dV/dt (Min) 1kV/μs
On-State Voltage-Max 2.5V
Input Trigger Current-Nom 5mA
Peak Surge Current 1A
Input Trigger Current-Max 0.005A
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
