EL3012S1(TB)
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Gull Wing
Category Isolators / Optoisolators - Triac, SCR Output
Description
6-SMD Gull Wing 1 Triac Active Optoisolator Triac Output 100V/mus (Typ) 5000Vrms 60mA -55C~100C
PDF
/
Inventory: 8163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, Gull Wing
Number of Pins 6
Technical
Operating Temperature -55°C~100°C
Packaging Tape & Reel (TR)
Published 2013
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Additional Feature UL RECOGNIZED
Approval Agency CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL
Voltage - Isolation 5000Vrms
Output Type Triac
Number of Elements 1
Configuration SINGLE
Number of Channels 1
Max Input Voltage 1.5V
Nominal Input Voltage 1.18V
Hold Current 250μA
Current - DC Forward (If) (Max) 60mA
Voltage - Off State 250V
Current - On State (It (RMS)) (Max) 100mA
Current - Hold (Ih) 250μA Typ
Zero Crossing Circuit No
Current - LED Trigger (Ift) (Max) 5mA
Static dV/dt (Min) 100V/μs (Typ)
Input Trigger Current-Nom 5mA
Compliance
RoHS Status ROHS3 Compliant
