OPIA4N33ATU
RoHS
/
Package 6-SMD, Gull Wing
Category Isolators / Optoisolators - Transistor, Photovoltaic Output
Description
OPTOISO 5KV DARL W/BASE 6SMD
PDF
/
Inventory: 4990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Current Transfer Ratio 4000%
Current Transfer Ratio (Min) 500% @ 10mA
Current - DC Forward (If) (Max) 50mA
Current - Output / Channel 150mA
Rise / Fall Time (Typ) 5μs 60μs
Collector Emitter Voltage (VCEO) 1V
Output Current per Channel 150mA
Optoelectronic Device Type DARLINGTON OUTPUT OPTOCOUPLER
Input Type DC
Voltage - Forward (Vf) (Typ) 1.2V
Number of Channels 1
Configuration SINGLE
Number of Elements 1
Output Type Darlington with Base
Output Voltage 30V
Voltage - Isolation 5000Vrms
Reach Compliance Code unknown
Additional Feature UL RECOGNIZED, VDE APPROVED
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2008
Packaging Tube
Operating Temperature -30°C~100°C
Physical
Package / Case 6-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
