PC852XPJ000F
RoHS
/
Package 4-SMD, Gull Wing
Category Isolators / Optoisolators - Transistor, Photovoltaic Output
Description
OPTOISOLATOR 5KV DARL 4SMD
PDF
/
Buying Options
Total Price: USD $0.5
Unit Price: USD $0.4978
≥1 USD $0.4978
≥10 USD $0.4085
≥100 USD $0.39615
≥500 USD $0.38285
≥1000 USD $0.3705
Inventory: 1594
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD, Gull Wing
Number of Pins 4
Technical
Operating Temperature -30°C~100°C
Packaging Cut Tape (CT)
Published 2005
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Copper (Sn/Cu)
Additional Feature UL RECOGNIZED
Max Power Dissipation 200mW
Reach Compliance Code unknown
Voltage - Isolation 5000Vrms
Output Voltage 350V
Output Type Darlington
Number of Elements 1
Configuration SINGLE WITH BUILT-IN DIODE AND RESISTOR
Power Dissipation 200mW
Input Type DC
Forward Current 50mA
Output Current per Channel 40mA
Rise Time 300μs
Fall Time (Typ) 100 μs
Collector Emitter Voltage (VCEO) 350V
Max Collector Current 150mA
Rise / Fall Time (Typ) 100μs 20μs
Current - Output / Channel 150mA
Reverse Breakdown Voltage 6V
Collector Emitter Saturation Voltage 1.2V
Current Transfer Ratio (Min) 1000% @ 1mA
Current Transfer Ratio 4000%
Dark Current-Max 200nA
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
